solar on grid inverter 1kw 2kw 3kw 4kw 5kw 8kw 10kw 12kw 15kw 20kw 25kw for grid tie solar system

  • >=399 Sets
    US $370.00
Type:
on grid inverter
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
YC On-grid inverter
Model Number:
grid tie inverter
Product name:
Solar Grid-connected Inverter
Application:
Solar Power System
Keyword:
grid tie inverter/og grid inverter
Warranty:
2 Years
Operate mode:
Solar Panel Module Machine
Power Supply:
AC380V 3phase 1kw-60kw
Package:
Standard Case
Power Battery Type:
No battery
Function:
on grid inverter
Item Name:
inverter for grid tie solar system
Supply Ability
Supply Ability:
999 Set/Sets per Month
Packaging & Delivery
Packaging Details
Standard package
Port
Ningbo/ Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(day) 15 To be negotiated
Product Description


YC On-grid Inverter Technical Parameters


One MPPT 1~3.6KW Single Phase

Electrical Specifications
1.0KW
 1.5KW
2.0KW
2.5KW
3.0KW
3.6kw
Input( DC)
Max DC Power (W)
1100
1600
2200
2700
3200
3200
Max DC Voltage (V)
450
450
500
500
500
550
Rate/ Recommended Voltage(V)
300
300
360
360
360
360
MPPT DC Voltage Range(V)
50-320
90-360
120-400
120-400
120-400
120-450
Start up DC Voltage(V)
55
100
150
150
150
150
Turn off DC Voltage(V)
47
82
120
120
120
120
Max DC Current (A)
10
10
14
14
17
18
Isc PV (A)
12.5
12.5
15
17.5
21
22
Number of MPPT Tracker
3
1
1
1
1
1
Number of DC Connections(set)
12
1
1
1
1
2
Max Backfeed Current(MA)
<1
<1
<1
<1
<1
<1
Ouput(AC)
Max AC Power (W)
1050
1550
2100
2600
3100
3700
Norminal AC Power(W)
1000
1500
2000
2500
3000
3600
Max AC Current (A)
6
9
12
13
15
16
Norminal AC Current(A)
6
8
10
12
13
16
Max. AC Inrush Current(A)
6
8
10
12
13
16
Max Fault Current (A)
9
12
15
18
19.5
24
Max. AC Protect Current(A)
9
12
15
18
19.5
24
Norminal AC Voltage(V)
220/230
220/230
220/230
220/230
220/230
220/230
Norminal AC Frequency(Hz)
50/60
50/60
50/60
50/60
50/60
50/60
Power Factor
-0.95~+0.95
Ouput Current THD
<3%
<3%
<3%
<3%
<3%
<3%
Feed in Starting Power(W)
42
40
30
30
30
30
Power Consumption
Power Consumption At Night(W)
<1
<1
<1
<1
<1
<1
Power Consumption At Standby(W)
6
6
6
6
6
6
Power Efficiency
Max Efficiency
97.70%
97.70%
97.70%
97.70%
97.70%
97.70%
Euro Efficiency
96.30%
96.50%
96.60%
96.90%
97.00%
97.00%
MPPT Efficiency
99.90%
99.90%
99.90%
99.90%
99.90%
99.90%
Safety & Protection
Safety Standard
IEC 62109-1/2, EN 61000-3-2, EN 61000-3-2,-3,-11,-12
Anti-islanding Protection
Internal
General information
Dimensions(WxHxD)(mm)
360*345*170
Enclosure
IP65
UV Protection
Metal/ Alluminium
Metal
RCD
0.977
Weight(kg)
12
14
Ambient Temperature Range
-20℃~+55℃
Relative Humidity
4%~100%(condensing)
Topology
Transformerless
Communication Interface
RS485 / WI-FI(Optional)
Cooling Concept
Convection
Noise Emission[dB]
<40
Maximum Altitude(above sea level)m
2000
